MT-7110 RF Connector BNC-J 50 Ohm Pure Copper Coaxial Connector

Temperature range: -65 to +165°C (PE cable -40 to +85°C)
Vibration: MIL-STD-202, Method 213
Characteristic impedance: 50Ω, 75Ω
Frequency range : DC to 4GHz
Operating voltage :500V max (RMS)
Withstand voltage: 1500V rms (sea level min)
Contact resistance
Center contact between inner conductors ≤ 1.5 mΩ
Between outer conductors ≤ 1 mΩ
Insulation resistance :≥5000 MΩ
VSWR Straight type ≤ 1.22
   Curved right angle ≤ 1.30
Durability (mating) ≥ 500 times (cycles)
Availability:
Quantity:


Product name:

RF Coaxial Connector

Country of origin:

Ningbo,China

Application:

Telecommunication System

Color:

Silver

Connector type:

RF Adaptor Connector

Name:

BNC Adaptor

Impedance:

50/75Ω


7110.jpg7110 (1).jpg7110 (2).jpg7110 (3).jpg7110 (4).jpg


Mechanical Field-Mountable Fiber Optic Connector is designed to simple the connection without fusion splicing machine. This connector is quick assembly which requires only normal fiber preparation tools: cable stripping tool and fiber cleaver. The connector adopts Fiber Pre-embed Tech with superior ceramic ferrule and aluminum alloy V-groove. Also, transparent design of the side cover which allows visual inspection.

Applicable to connection with field mountable indoor cable, pigtail, patch cord and transformation of patch cord in data room and directly used in specific ONU.
