MT-GM1023
1、Product Overview
ONU product is the terminal equipment of a series of xPON which comply fully with ITU-G.984.1/2/3/4 standard and meet the energy-saving of G.987.3 protocol,ONU is based on mature and stable and high cost-effective XPON technology which adopts high-performance xPON REALTEK chipset and has high reliability， easy management，flexible configuration，robustness，good quality service guarantee(Qos).
This ONU supports WIFI4 (IEEE802.11b/g/n) and WIFI5 (IEEE802.11ac) concurrently ,a WEB system provided simplifies the configuration of the WIFI and connects to INTERNET conveniently for users.
ONU supports the G/E PON switching function automatically
ONU supports a RJ11 interface for VOIP applications
2、Product Features
△ comply fully with ITU-G.984.1/2/3/4 standard and G.987.3 protocol
△ support downlink 2.488 Gbits/s rate and uplink 1.244 Gbits/s rate
△ support bidirectional FEC and RS(255,239) FEC CODEC
△ support 32 TCONT and 32 GEMPORT
△ support AES128 decryption function of G.984 standard
△ support SBA and DBA dynamically broadband allocation
△ support the PLOAM function of G.984 standard
△ support Dying-Gasp check and report
△ support synchronous Ethernet
△ good interworking with the OLT from different manufacturers，such as HuaWei ,ZTE,Cortina etc
△ down-link LAN ports: 4*10/100/1000M with auto-negotiation
△ support the rogue ONU alarm function
△ Support VLAN function
△ operation mode: HGU
△ support IEEE802.11b/g/n and IEEE802.11ac standard for WIFI
△ antennas gain: 5DBi with external
△ support: 300Mbps PHY rate IEEE802.11n, 866Mbps PHY rate IEEE802.11ac
△ support multiply SSID
△ Multiple encryption methods:WFA、WPA、WPA2、WAPI
△ one port for VOIP，support SIP protocol optional
△ comply fully with IEEE802.3ah standard and CTC-3.0 specification
